Main Application Fields
Rodent Research Applications
√ Deep brain injections in guinea pigs, rats, and mice for viruses, drugs, neurotransmitters, or dyes
√ Oocyte and embryo injections in guinea pigs, rats, and mice for genetic material, drugs, or dyesZebrafish Research Applications
√ Zebrafish oocyte gene or dye injection
√ In vivo injections in zebrafish larvaeInsect Research Applications
√ Oocyte injections in nematodes, worms, fruit flies, cotton bollworms, brown planthoppers, etc.
√ In vivo drug or dye injections in nematodes and worms
√ In vivo drug or dye injections in fruit flies, cotton bollworms, and brown planthoppersXenopus Oocyte and Tadpole Injections
Performance Advantages
※ Multiple operation modes: homing, emptying, sampling, and programmable injection
※ High precision: injection volumes as low as <1 nl
※ Hydraulic technology ensures consistent injection volume
※ Injection methods: single manual injection or programmable injection with auto-save
※ User-friendly touchscreen operation
※ Expandable potential applications based on requirements
※ Easy-to-use micro-pipetting and injection capillaries
※ No O-ring required; simple assembly with effective sealing
Technical Parameters
5-inch LCD touchscreen with one-key Chinese/English switching
Stroke: 25 mm
Capillary dimensions: OD 0.045″ (1.14 mm), ID 0.021″ (0.53 mm)
Flow rate range: 0.295 nl – 12.763 μl/min
Adjustment resolution: 7.9 μm/min
Stroke resolution: 0.165 μm
Rated linear thrust: 20 N
Setting method: Touchscreen configuration
Control accuracy: ≤0.5% error at ≥30% full stroke
External control interface: Start/stop, fast forward, fast reverse
Communication interface: RS485; Power supply: AC 220 V ±10%, 50/60 Hz; Power consumption: <10 W
Operating environment: 0–40°C, relative humidity <80%
Dimensions (L × W × H): 180 × 46 × 78 mm
This pump offers researchers a versatile and precise tool for a wide range of microinjection applications across multiple biological models and disciplines.
