Key Features:

1. 5-channel design supports concurrent anesthesia for 5 animals

2. Suitable for animals weighing up to 5.2 kg, including rodents such as rats and mice

3. Dual breathing circuits with closed-loop gas path design

4. Imported flowmeters with adjustable range of 0-1000 mL/min, ensuring precise adjustment for low-flow small animal anesthesia

5. Lightweight unibody sheet metal construction for enhanced portability

6. Vaporizer with automatic flow and temperature compensation, adjustable in 0.5% increments

7. Stable isoflurane vapor output with excellent sealing; safe and reliable operation with adjustable output concentration of 0-5%

8. Optional negative pressure scavenging system with real-time concentration monitoring and controllable activated carbon replacement cycle

9. Compact and aesthetically pleasing design with built-in auto-lock knobs for user-friendly operation

10. Transparent animal induction chamber for clear observation of anesthesia depth

11. Surgical masks adaptable for rats and mice; nasal interface size can be customized based on animal size

12. Dedicated valve for simultaneous connection to pre-anesthesia chamber and surgical platform

13. Waste gas scavenging system to ensure laboratory safety

Technical Specifications:

1. Main Unit Dimensions: 350 × 180 × 280 mm (L × W × H, including handle)

2. Power Supply: 220V, 50Hz

3. Gas Output: 0-10 L/min

4. Output Concentration: 0.5%-5% adjustable

5. Flowmeter Range: 0-1000 mL/min (5 channels total)

6. Exhaust Filter: Transparent housing with replaceable filter media

7. Compatible Filter Materials: Activated carbon or soda lime

8. Anesthesia Induction Chamber: Transparent material, Dimensions: 260 × 150 × 150 mm

9. Compatible Anesthetic: Isoflurane

10. System Components:

    • 1 small animal anesthesia main unit

    • 1 gas delivery unit

    • 1 anesthesia filter

    • 1 pre-anesthesia chamber

    • 1 surgical platform set

    • 1 set of animal masks
