Product Features:

1. Designed specifically for small animals up to 5.2 kg, including rodents such as rats and mice

2. Single breathing circuit with non-recirculating gas path minimizes dead space

3. Precision glass tube flowmeter with 0-1000 mL/min adjustment range enables accurate low-flow anesthesia

4. Molded unibody construction ensures lightweight portability

5. UK-sourced vaporizer features automatic flow and temperature compensation with 0.5% adjustment increments

6. Stable isoflurane delivery system with 0-5% concentration adjustment and verified sealing integrity

7. Professional filling adapter simplifies anesthetic replenishment

8. Compact design with integrated auto-lock knobs for intuitive operation

9. Transparent induction chamber permits clear observation of anesthesia depth

10. Specialized surgical platform with species-specific masks, including customizable options for rodents

11. Dedicated dual-purpose valve interfaces with both pre-anesthesia chambers and surgical platforms

12. Integrated waste gas scavenging system maintains laboratory safety

Technical Specifications:

1. Maximum Configurable Channels: 1-4

2. Power Supply: 220V 50Hz

3. Gas Output Range: 0-10 L/min

4. Anesthetic Concentration: 0.5%-5% adjustable

5. Main Flowmeter (US-sourced): 0-5000 mL

6. Branch Channel Flowmeters: 0.1-1000 mL per channel

7. Exhaust Filter: Transparent housing with replaceable media

8. Compatible Filter Materials: Activated carbon or soda lime

9. Induction Chamber: 10 mm acrylic, 260 × 150 × 150 mm

10. Compatible Anesthetic: Isoflurane

11. Vaporizer Origin: United Kingdom

12. System Components:

    • 1 anesthesia main unit

    • 1 gas supply unit

    • 1 anesthesia filter

    • 1 pre-anesthesia chamber

    • 4 surgical platforms

    • 4 animal mask sets

    • 1 gas distribution valve assembly
